SPECIFICATIONS

• SKU: 66136
• Model Number: EZ-9000GR
• Type: Compact Auto
• RP Model: No
• Auto Feed: Yes
• Tape Max Width in: 0 – 5 in
• Tape Max Width mm: 20 – More mm
• Tape Width – Imperial: 0.24 in to 2.4 in.
• Tape Width – Metric: 6 to 60 mm
• Cut Max Length in: 20 – More in
• Cut Max Length mm: 20 – More mm
• Cut Length – Imperial: 0.2 to 39 in
• Cut Length – Metric: 5 to 999 mm
• Maximum Outside Diameter of Tape Roll – Imperial: 11.8 in
• Maximum Outside Diameter of Tape Roll – Metric: 300 mm
• Electrical Requirements: 100V | 50Hz – 60Hz
• Rolls of Tape: 1 or 2
• Dimensions – Imperial: 4.6 x 5.5 x 8.4 in. (WxHxD)
• Dimensions – Metric: 116 x 140 x 213 mm (WxHxD)
• Weight – Imperial: 3.5 lbs
• Weight – Metric: 1.6 kg
• Double Sided Tape: Contact ASG
• ESD Safe: No
• Length Setting: Digital
• Warranty: 6 Months

• Up to six different cut lengths can be programmed to cut by selection or in sequence
• Modular blade and roller unit allows for easy on-site maintenance
• Dual photo sensors allow two rolls of tape to be cut at the same time
• Tape support to position a cut piece of tape
• Cuts non-adhesive tapes
• Pre-set and loop counter
• No bobbin needed
• Uses a range of tape thickness, from 0.002 in. to 0.012 in. (0.05 mm to 0.3 mm)
• Usable tapes include but are not limited to:
  • Craft, PP, Vinyl, Filament, Glass Cloth, Double-Sided, Strapping, Protective Film, Aluminum Foil
• Accessories included: Built-In Separator (for cutting two tape rolls), Blade Oil, Guide Plate, Tweezers, Power Cord
• Body Material: Anti-Static ABS
• Rated Voltage: AC 100 V 240 V, 50/60HZ, 25 W, Fuse 2A (AC Inlet Build-in)
• Arm mount kit available- ASG Number 66138
• RP model available ASG #66161: Cuts tape while removing the paper backing
