SPECIFICATIONS

• SKU: 66143
• Model Number: TD-100RP
• Type: Compact Auto w/ Backing Removal
• RP Model: Yes
• Auto Feed: Yes
• Tape Max Width in: 0 – 5 in
• Tape Max Width mm: 20 – More mm
• Tape Width – Imperial: 0.24 to 2.4 in.
• Tape Width – Metric: 6 to 60 mm
• Cut Max Length in: 20 – More in
• Cut Max Length mm: 20 – More mm
• Cut Length – Imperial: 0.2 in to 39 in
• Cut Length – Metric: 5 to 999 mm
• Maximum Outside Diameter of Tape Roll – Imperial: 5.91 in
• Maximum Outside Diameter of Tape Roll – Metric: 150 mm
• Electrical Requirements: 100-240V
• Rolls of Tape: 1 or 2
• Dimensions – Imperial: 4.57 x 11.9 x 12.6 in. (WxHxD)
• Dimensions – Metric: 116 x 302 x 320 (WxHxD)
• Weight – Imperial: 5.5 lbs
• Weight – Metric: 2.5 kg
• Double Sided Tape: Contact ASG
• ESD Safe: No
• Length Setting: Digital
• Warranty: 6 Months

• RP Model cuts tape with while removing the backing paper
• Compact and versatile dispenser
• Designed for industrial or commercial use
• Presets a piece of tape cut to a precise length
• Tape support to position a cut piece of tape
• Memory function can program 6 different lengths
• Can accommodate 1 or 2 rolls of tape
• Cut length of 0.169 to 39 inches (5 to 999 mm)
• Anti-static ABS body
• 2 Dispensing Modes:
• Pre-Set: Allows cutting of pre-selected number of pieces; machine stops, and alarm sounds when complete
• Loop: Allows continuous cutting and dispensing up to a designated number
• Cuts a large variety of adhesive and non-adhesive material:
• Tape: Filament, Strong, Acetate Cloth, Glass Cloth, Nomex, Prestick, Cellophane, Craft, Masking, Plastic, and more
• Non-Adhesive: Protection Film, Paper Tape, Insulation Film, Aluminum Foil, Copper Foil, and more
• LED counter tracks the number of cuts
