SPECIFICATIONS

• SKU: 28M20D-D10
• Model Number: 28M20D-D10
• Output Shaft Type: Low Rotation Smooth Output Shaft
• Torque at Max. Power – Imperial: 70.8 lbf.in*
• Torque at Max. Power – Metric: 8 N.m*
• No Load Speed: 215 RPM
• Air Consumption at Max. Power: 12.7 CFM
• Power: 280 W | 0.38 HP
• Reversibility: Non-Reversible
• Weight – Imperial: 2.13 lb.
• Weight – Metric: 0.97 kg
• Warranty: 2 years

• *Maximum torque permitted: 8 N.m for 28M
• Innovative design insures reliable motor starting even at low air pressure
• Low vibration levels
• Does not overheat in difficult, heavy duty conditions, repetitive start/stops or repetitive reversing
• Highly effective due to compact size, high power output and low air consumption
• Designed using materials and processes that minimize the effects on the environment
• Customized models are available upon request
• Suitable for many applications: mixing, moving, components positioning, various movements
• Smooth shaft 10mm with UNI 6604 Form A key slot
