5 HP Two-Stage Industrial Air Compressor

(0 customer reviews)

$2,863.00$146.00

SKU: GrJVvCWQ
Category: Pneumatic (Air) Tools

Add To Cart

30 days easy returns
Order yours before 2.30pm for same day dispatch

Product Description

Stationary Electric Air Compressors

5 HP, two-stage electric stationary air compressors on a variety of tank configurations. Model V5180K30 shown.

Optional Equipment: Magnetic Starter, Automatic Tank Drain, Low Oil Shut Down, Vibration Pads, Dual Controls, Head Unloader, Refrigerant Air Dryer, Air Cooled Aftercooler

About The Pump

Two-Stage
Cast-Iron Cylinders
Aluminum Head and Crankcase for Faster Heat Dissipation
Ball Bearings
Splash Lubricated
Bearing Inserts on Connecting Rods
Swedish Lammelar Reed Valves
Oil Sight Gauge
Low RPMs to Ensure Long Life and Trouble-Free Performance

About The Motor

1740 RPM
60 Hz
Open Drip-Proof Motor
Single Phase Models Available in 208 and 230 Volt
Three Phase Models Available in 208, 230, and 460 Volt

Standard Equipment

Pressure Switch – Start/Stop Operation
145-175 PSI Settings
On/Off Switch
Automatic Unloading Device for Loadless Starts
Heavy Duty Brass Shut-Off Valve
Pressure Gauge, 0-300 PSI in 5 lb. Graduations
Safety Relief Valve – ASME Approved
Multiple V-Belt Drive
Intake Filter/Silencer with Replaceable Element
Totally Enclosed Steel Belt Guard

Specifications

HORSE POWER	5 HP
CFM DISPLACED	20.6 – 23.1 CFM
CFM DELIVERED	15.3 – 18.0 CFM
LUBRICATION TYPE	Splash Lubrication
REED VALVE SYSTEM	Yes (Standard)
NUMBER OF CYLINDERS	2
COUNTRY OF ORIGIN	Compressor Origin.pdf

Additional Models

MODEL #	HP	PHASE	TANK SIZE	MOTOR RPM	CFM DISPLACED	CFM DELIVERED
H5160K30	5	Single	60 Gallons, Horizontal	1740	23.1 @ 175 PSI	18.0 @ 175 PSI
V5160K30	5	Single	60 Gallons, Vertical	1740	23.1 @ 175 PSI	18.0 @ 175 PSI
H5112K30	5	Single	120 Gallons, Horizontal	1740	23.1 @ 175 PSI	18.0 @ 175 PSI
V5112K30	5	Single	120 Gallons, Vertical	1740	23.1 @ 175 PSI	18.0 @ 175 PSI
H5360K30	5	Three	60 Gallons, Horizontal	1740	23.1 @ 175 PSI	18.0 @ 175 PSI
V5360K30	5	Three	60 Gallons, Vertical	1740	23.1 @ 175 PSI	18.0 @ 175 PSI
V5380K30	5	Three	80 Gallons, Vertical	1740	23.1 @ 175 PSI	18.0 @ 175 PSI
H5312K30	5	Three	120 Gallons, Horizontal	1740	23.1 @ 175 PSI	18.0 @ 175 PSI
V5312K30	5	Three	120 Gallons, Vertical	1740	23.1 @ 175 PSI	18.0 @ 175 PSI
V5180K30	5	Single	80 Gallons, Vertical	1740	23.1 @ 175 PSI	18.0 @ 175 PSI
H5160K28	5	Single	60 Gallons, Horizontal	1740	20.6 @ 175 PSI	15.3 @ 175 PSI
V5160K28	5	Single	60 Gallons, Vertical	1740	20.6 @ 175 PSI	15.3 @ 175 PSI
V5180K28	5	Single	80 Gallons, Vertical	1740	20.6 @ 175 PSI	15.3 @ 175 PSI
H5112K28	5	Single	120 Gallons	1740	20.6 @ 175 PSI	15.3 @ 175 PSI
V5112K28	5	Single	120 Gallons, Vertical	1740	20.6 @ 175 PSI	15.3 @ 175 PSI
H5360K28	5	Three	60 Gallons, Horizontal	1740	20.6 @ 175 PSI	15.3 @ 175 PSI
V5360K28	5	Three	60 Gallons, Vertical	1740	20.6 @ 175 PSI	15.3 @ 175 PSI
V5380K28	5	Three	80 Gallons, Vertical	1740	20.6 @ 175 PSI	15.3 @ 175 PSI
H5312K28	5	Three	120 Gallons, Horizontal	1740	20.6 @ 175 PSI	15.3 @ 175 PSI
V5312K28	5	Three	120 Gallons, Vertical	1740	20.6 @ 175 PSI	15.3 @ 175 PSI
